Power range
· 10k-600kVA
· Parallel connection can achieve 2400kVA
· Power module 40kVA, 50kVA
Performance characteristics
· Apply digital control
· Single power up to 600kVA, support 4 parallel operation
· 19-inch standard cabinet
· The monitoring module has the hot swap function
· Centralized monitoring module
· Equipped with EPO emergency stop button
· Large LCD color display with touch function
· Module adopts independent control system
· Each module adopts DC cooling fan
· Module comes with display screen
· The number of external batteries is optional
Application field
Post and telecommunications, electric power, communications and other industries, enterprises and institutions network room and data center.
Bropower BODM series N+X modular UPS power supply products are fully digital power supply products designed and developed by combining the technical characteristics of traditional tower models with the modular requirements of modern computer rooms, providing various specifications of power modules and cabinet systems, users can flexibly configure according to load requirements. A single cabinet can be configured with a capacity of 600kVA, and a parallel cabinet can be configured with a capacity of 2400kVA. The product has high working efficiency, high power density and perfect detection and protection functions; With optional communication interface, humanized design of monitoring software, easy to achieve centralized monitoring and remote monitoring of UPS.
