Power range
· 6/12 pulse 10kVA-300kVA
· Thyristor /IGBT rectifier
· The parallel connection can achieve 20000kVA
Performance characteristics
· Double transformation online
· Wide voltage range input, output completely isolated
· Dual-core DSP full digital control
· Sixth generation IGBT devices + advanced SVPWM (space vector modulation) technology
· Three-phase partial regulation, balanced voltage regulation
· Advanced redundant parallel technology, easy expansion
· GCI grid-connected operation function
· Perfect protection function
· Reliable carrying capacity
· Industrial design, adapt to harsh electrical environment
· Friendly man-machine interface, equipped with large Chinese LCD touch screen
· Rich network monitoring interface: RS232\RS485\RJ45\ dry contact can be equipped with Wi-Fi function, intelligent monitoring of UPS power equipment with mobile phones or tablets
Application field
Widely used in rail transit, data centers, oil fields, public security, military, communications, radar stations, electric power, industrial sites, airports, radio and television, banking, securities and medical systems and other industries.
Boditong power frequency BOD series is 3PH in/3PH out double conversion online UPS, capacity from 10kVA~300kVA, this series of UPS uses the 6th generation IGBT power device and static switch, the application of the latest dual-core DSP to achieve full digital control; Adopts industrial high standard design, the internal electrical connection adopts conductive alloy outsourcing low-smoke halogen-free resin, can withstand 20,000 volts high voltage, clear wiring, beautiful structure, good heat dissipation, greatly reducing the volume and weight of the power supply; It has perfect detection and protection functions, and the parameter indicators basically reach the level of national standards. It adopts color LCD touch screen with Chinese and English interface, RS232, RS485 and other interfaces, and optional SNMP card to realize intelligent UPS monitoring.
