Power range
· 10k-100kVA
· 1000kVA can be realized in parallel
Performance characteristics
· Double transformation online
· High IP protection level
· Input and output isolation transformers
· Adopt full digital control technology
· LED+LCD color LCD display
· Intelligent detection and monitoring function
· Optional dry contact interface
· Optional input harmonic filter or 12-pulse rectifier
· Improve protection function
· Wide input voltage range
· RPA (Redundant parallel) function
· The parallel system adopts advanced synchronous current sharing control technology
· The circuit boards used all adopt the three-prevention process
· Optional Wi-Fi function, smart monitoring of UPS power equipment with mobile phone or tablet computer
Application field
The environment is relatively harsh industrial site, such as subway, power plant, smelting, drilling platform, navigation, chemical industry, ceramics, jewelry processing and other fields.
Bropower BOT-DL Industrial power type UPS is for such as power system, power station, transmission system, smelting, chemical, ceramics, oil field and other harsh industrial sites, and research and development of high-reliability industrial UPS. Capacity 10kVA~100kVA, full digital control technology, power device selection of low-loss high-power IGBT, strong overload capacity, with perfect detection and protection functions; Use large LCD touch screen in Chinese and English, standard RS232 interface, optional SNMP network adapter card or RS485 card, to achieve centralized monitoring and remote monitoring of UPS; With RPA (redundant parallel) function, can realize 32 UPS parallel; Designed service life of more than 15 years.
